Applications: Ideal for manufacturing, automotive, textiles, food & beverage, pharmaceuticals, and electronics industries, where stable air supply and energy efficiency are critical.
| Model | ETSVII-22A | ETSVII-37A | ETSVII-45A | ETSVII-55A | ETSVII-75A | ETSVII-90A | ETSVII-110A | ETSVII-132A | |
|---|---|---|---|---|---|---|---|---|---|
| Air Flow & Pressure (m³/min / MPa) | 0.7 MPa | 4.1 | 6.9 | 8.9 | 11.2 | 15.1 | 20.0 | 22.0 | 26.0 |
| 0.8 MPa | 4.0 | 6.8 | 8.8 | 11.0 | 15.0 | 19.8 | 21.2 | 25.8 | |
| 1.0 MPa | 3.4 | 6.2 | 7.8 | 9.7 | 12.4 | 17.9 | 19.8 | 23.5 | |
| Air Supply Temperature | ≤ Ambient temperature + 8 ~ 15°C | ||||||||
| Motor Specs | Power (kW/HP) | 22/30 | 37/50 | 45/60 | 55/75 | 75/100 | 90/120 | 110/150 | 132/175 |
| Start Method | VSD Start | ||||||||
| Voltage | 380V 3PH 50HZ (Other voltages can be customized) | ||||||||
| Drive Method | Integrated air end and motor | ||||||||
| Oil Content (PPM) | ≤ 3 | ||||||||
| Connector Size (Inch) | 1" | 1 1/2" | 2" | 2" | 2" | 2 1/2" | 2 1/2" | 2 1/2" | |
| Dimensions (mm) | Length (mm) | 1254 | 1455 | 1754 | 7854 | 1914 | 2454 | 2454 | 2454 |
| Width (mm) | 900 | 1100 | 1200 | 1300 | 1300 | 1500 | 1500 | 1500 | |
| Height (mm) | 1190 | 1300 | 1550 | 1550 | 1600 | 1840 | 1840 | 1840 | |
| Weight (kg) | 450 | 580 | 925 | 970 | 1170 | 1746 | 1750 | 1790 | |
