ODM Low Noise Dry Type Oil Free Screw Air Compressor oilless industrial air compressor rotary air compressor Exporter, Exporters

1. 280kW dry oil-free screw compressor, fixed speed & VSD PM options. 2. 100% oil-free clean air, energy-saving and eco-friendly. 3. High-efficiency two-stage compression for lower power consumption. 4. Easy maintenance and low operating noise.

Send Inquiry

Product Description

Air-End

Premium name brand air-end research & development experience.
High technology content air-end, offering an average of 8-10% energy saving.
Owned design gearbox, ensuring reliability & durability.

High Efficiency & Save Energy Motor

High efficiency & energy saving intake valve, keeping lower unloading pressure and avoiding large energy consumption when unloading.
New oil tank design, lower pressure drop and less energy consumption.
Shortest piping system in order to reduce the pressure drop.
Oversized air/oil separator to bring down the pressure drop.
Optimized cooler design, less elbow.

Reliability & Safety

Reliability bigger cooler, lower operating temperature.
Safety and reliability filter system.
Integrated fan, stable and high efficiency.
Reinforced cabinet, strong & safety.

Low Noise & Vibration

Air-end built with optimized configuration for low noise & vibration.
Motor equipped with noise reduction baffle.

Easy Installation & Operation

Compressor is filled with lubrication oil before shipping. You can operate it after installing and power on.
PLC intelligent control system, has the remind & record function, show the compressor situation clearly.
Friendly use, open the door can fulfill the common maintenance.
Cooler and fan easy to clean.

Smart Controller & PLC

Intelligent screen touch panel.
Branded PLC system (Origin from France) protecting your compressor running.
Customizable language version display.

The whole machine adopts low speed, high wind fan and large plate cooler to reduce air convection friction and provide comfortable and quiet environment.

Model		EOF-55W	EOF-75W	EOF-90W	EOF-110W	EOF-132W	EOF-145W	EOF-160W	EOF-200W	EOF-250W	EOF-315W
Free air delivery / Discharge air pressure (m³/min / MPa)	0.75 MPa	8.8	11.9	14.3	19.1	21.9	23.5	28.3	36.1	43.1	46.4
	0.85 MPa	7.9	11.2	13.5	17.1	19.6	21.7	26.1	33.1	41.0	43.0
	1.0 MPa	7.3	10.7	12.7	16.0	18.9	20.1	24.2	30.4	37.4	41.0
Motor	Power (kw/hp)	55/75	75/100	90/120	110/150	132/175	145/200	160/215	200/270	250/355	315/420
	Start method	VSD Starter / Star Triangle
	Voltage (v/hz)	380V 3PH 50HZ (Optional: 380V-3PH-60HZ / 460V-3PH-60HZ / 220V-3PH-60HZ / 400V-3PH-50HZ / other customizable voltages)
Drive method		Direct Drive
Connector inch		2"	2"	DN65	DN65	DN80	DN100	DN100	DN100	DN100	DN150
Dimension	Length (mm)	2630	2630	2630	2630	3200	3200	3200	3200	3500	3500
	Width (mm)	1788	1788	1788	1788	1980	1980	1980	1980	2100	2100
	Height (mm)	1900	1900	1900	1900	2000	2000	2000	2000	2200	2200
Weight (kg)		2300	2500	2800	2980	3100	3300	3500	3800	4200	4800

100% oil-free: suitable for medical, pharmaceutical, precision electronics and food and beverage industries with strict air quality and production process requirements.

Frequently Asked Questions (FAQ)

What industries are these oil-free air compressors suitable for?

These 100% oil-free compressors are highly suitable for industries with strict air quality and production process requirements, including the medical, pharmaceutical, precision electronics, and food and beverage industries.

How does the compressor achieve energy savings?

The system achieves an average of 8-10% energy savings through a combination of high-technology air-ends, an energy-saving intake valve that reduces unloading pressure, an optimized new oil tank design, the shortest piping system layout, and oversized air/oil separators.

What are the noise reduction features of this unit?

The unit adopts a low-speed, high-wind fan, a large plate cooler to minimize air convection friction, and a motor configured with a noise reduction baffle to ensure a quiet and comfortable operating environment.

Is the compressor ready for use upon delivery?

Yes, the compressor is pre-filled with lubrication oil before shipping. You can operate the machine immediately after completion of physical installation and connecting the power supply.

Can the controller language be customized?

Yes, the intelligent touch-screen PLC control system supports customized language versions according to your region and operating preferences.
