The OSG single-stage, frequency-standard screw air compressor features low energy consumption, high capacity, and superior design and manufacturing.  It reduces daily maintenance requirements, perfectly replacing reciprocating air compressors, and offers intelligent remote control, simplifying complex operations. Screw Air Compressor Features: ■ 1:1 direct drive for low noise and energy consumption, effectively protecting the motor torque. ■ High-quality sound-absorbing materials and enclosure ensure operating noise remains within ideal levels, providing a quiet and comfortable working environment. ■ Fewer moving parts lead to stable performance and low maintenance costs. ■ Compact design with a sleek and elegant appearance, saving space. ■ Removable air duct cover for easy maintenance. ■ Intelligent control system for simple operation. Screw Compressor Control and Electrical System: ■ RS485 communication for data collection and integration into the user's central control panel for monitoring. ■ Intelligent controller dynamically adjusts control accuracy for precise torque control. ■ Real-time display of operating parameters, maintenance alerts, energy management, and data analysis via mobile phone or computer.

Product Description

Technical Specifications (Models 10A - 60A)

Model 10A 15A 20A 25A 30A 40A 50A 60A
Free air delivery / Discharge pressure (m³/min / MPa) 1.2/0.7 1.65/0.7 2.5/0.7 3.2/0.7 3.8/0.7 5.3/0.7 6.8/0.7 7.4/0.7
1.1/0.8 1.5/0.8 2.3/0.8 3.0/0.8 3.6/0.8 5.0/0.8 6.2/0.8 7.0/0.8
0.95/1.0 1.3/1.0 2.1/1.0 2.7/1.0 3.2/1.0 4.5/1.0 5.6/1.0 6.2/1.0
0.8/1.25 1.1/1.25 1.9/1.25 2.4/1.25 2.7/1.25 4.0/1.25 5.0/1.25 5.6/1.25
Lubricating oil quantity (L) 4 7.5 14 14 14 30 30 30
Driving mode Direct drive
Power supply 380V/50Hz/3P or customized
Power (kW) 7.5 11 15 18.5 22 30 37 45
Startup mode Y-Δ start-up
Dimension (mm) 850*670*870 1100*750*920 1250*850*1160 1350*1000*1190
Outlet diameter G1 G1 G1 G1¼ G1¼ G1¼

Technical Specifications (Models 75A - 350A)

Model 75A 100A 120A 150A 175A 200A 250A 300A 350A
Free Air Delivery / Discharge Pressure (m³/min / MPa) 10.0/0.7 13.4/0.7 16.2/0.7 21.0/0.7 24.5/0.7 28.7/0.7 32.0/0.7 36.0/0.7 42.0/0.7
9.6/0.8 12.6/0.8 15.0/0.8 19.8/0.8 23.2/0.8 27.6/0.8 30.4/0.8 34.3/0.8 40.5/0.8
8.5/1.0 11.2/1.0 13.8/1.0 17.4/1.0 20.5/1.0 24.6/1.0 27.4/1.0 30.2/1.0 38.2/1.0
7.6/1.25 10.0/1.25 12.3/1.25 14.8/1.25 17.4/1.25 21.5/1.25 24.8/1.25 27.7/1.25 34.5/1.25
Lubricating Oil Quantity (L) 65 65 72 90 90 110 110 125 125
Driving Mode Direct drive
Power (kW) 55 75 90 110 132 160 185 220 250
Startup Mode Y-Δ Start-up
Dimension (mm) 1800*1230*1570 1900*1230*1570 2300*1470*1840 2650*1650*2045 3300*2100*2190
Weight (kg) 1073 1272 1327 1801 1848 2400 2600 3100 3300
Outlet Diameter G2 G2 G2 G2½ G2½ G2½ G2½ DN100 DN100

Frequently Asked Questions (FAQ)

What driving mode is used in these air compressor models?

All models in this series, from 10A up to 350A, utilize a Direct Drive system to ensure maximum transmission efficiency and reliable performance.

What is the standard startup mode for these compressors?

The standard configuration for all models is Y-Δ (Star-Delta) start-up, which effectively reduces starting current and minimizes electrical load impact during start.

Can the power supply configurations be customized?

Yes. While the standard power supply configuration is 380V/50Hz/3P, custom voltage and frequency configurations can be provided to meet your specific regional power grid requirements.

How does the lubricating oil quantity differ between smaller and larger models?

The lubricating oil requirements scale based on system capacity, ranging from 4 liters for the compact 10A model to 125 liters for the high-capacity 300A/350A models to ensure optimal cooling and lubrication.

What types of outlet connection sizes are available?

Outlet configurations range from small G¼ threaded connections for low-flow models to standard thread sizes like G1, G1¼, G2, G2½, and DN100 flange connections for large industrial models (300A and 350A).
