| XZV- series technical parameters: | |||||||||||
| Model | XZV-8A | XZV-11A | XZV-15A | XZV-18A | XZV-22A | XZV-30A | XZV-37A | XZV-45A | XZV-55A | XZV-75A | |
| Free air delivery / Discharge air pressure (m³/min / MPa) | 1.1 / 0.7 | 1.8 / 0.7 | 2.5 / 0.7 | 3.0 / 0.7 | 3.7 / 0.7 | 5.0 / 0.7 | 6.5 / 0.7 | 7.4 / 0.7 | 10.0 / 0.7 | 13.4 / 0.7 | |
| 1.0 / 0.8 | 1.7 / 0.8 | 2.3 / 0.8 | 2.9 / 0.8 | 3.5 / 0.8 | 4.8 / 0.8 | 6.2 / 0.8 | 7.0 / 0.8 | 9.6 / 0.8 | 12.6 / 0.8 | ||
| 0.9 / 1.0 | 1.5 / 1.0 | 2.0 / 1.0 | 2.7 / 1.0 | 3.1 / 1.0 | 4.3 / 1.0 | 5.6 / 1.0 | 6.2 / 1.0 | 8.5 / 1.0 | 11.2 / 1.0 | ||
| 0.7 / 1.3 | 1.2 / 1.3 | 1.7 / 1.3 | 2.2 / 1.3 | 2.6 / 1.3 | 3.6 / 1.3 | 4.5 / 1.3 | 5.5 / 1.3 | 7.2 / 1.3 | 9.8 / 1.3 | ||
| Air supply temperature | ≤ ambient temperature +8~15 °C | ||||||||||
| Motor | Power (kw/hp) | 7.5 / 10 | 11 / 15 | 15 / 20 | 18.5 / 25 | 22 / 30 | 30 / 40 | 37 / 50 | 45 / 60 | 55 / 75 | 75 / 100 |
| Start method | VSD Starter | ||||||||||
| Voltage (v/hz) | 380V 3PH 50HZ (380V-3PH-60HZ / 460V-3PH-60HZ / 220V-3PH-60HZ / 400V-3PH-50HZ / 6000V-3PH-50HZ / other voltages customized) | ||||||||||
| Drive method | Coupling transmission | ||||||||||
| Oil content (PPM) | ≤ 3 | ||||||||||
| Connector inch | 3/4" | 3/4" | 1" | 1" | 1" | 1 1/4" | 1 1/4" | 1 1/2" | 1 1/2" | 2" | |
| Noise (dB) ±2 | 66 | 68 | 68 | 68 | 68 | 68 | 72 | 72 | 75 | 78 | |
| Dimension | Length (mm) | 900 | 1100 | 1100 | 1060 | 1060 | 1060 | 1500 | 1500 | 1800 | 1900 |
| Width (mm) | 700 | 750 | 750 | 820 | 820 | 820 | 1000 | 1000 | 1230 | 1230 | |
| Height (mm) | 930 | 1000 | 1000 | 1220 | 1220 | 1220 | 1290 | 1290 | 1570 | 1570 | |
| Weight (kg) | 140 | 200 | 210 | 235 | 296 | 336 | 443 | 466 | 834 | 917 | |
