| XZV-Series Technical Parameters | |||||||||||
| Model | XZV-8A | XZV-11A | XZV-15A | XZV-18A | XZV-22A | XZV-30A | XZV-37A | XZV-45A/ | XZV-55A | XZV-75A | |
| Free Air Delivery / Discharge Air Pressure (m³/min / MPa) | 0.7 MPa | 1.1/0.7 | 1.8/0.7 | 2.5/0.7 | 3.0/0.7 | 3.7/0.7 | 5.0/0.7 | 6.5/0.7 | 7.4/0.7 | 10.0/0.7 | 13.4/0.7 |
| 0.8 MPa | 1.0/0.8 | 1.7/0.8 | 2.3/0.8 | 2.9/0.8 | 3.5/0.8 | 4.8/0.8 | 6.2/0.8 | 7.0/0.8 | 9.6/0.8 | 12.6/0.8 | |
| 1.0 MPa | 0.9/1.0 | 1.5/1.0 | 2.0/1.0 | 2.7/1.0 | 3.1/1.0 | 4.3/1.0 | 5.6/1.0 | 6.2/1.0 | 8.5/1.0 | 11.2/1.0 | |
| 1.3 MPa | 0.7/1.3 | 1.2/1.3 | 1.7/1.3 | 2.2/1.3 | 2.6/1.3 | 3.6/1.3 | 4.5/1.3 | 5.5/1.3 | 7.2/1.3 | 9.8/1.3 | |
| Air Supply Temperature | ≤ ambient temperature +8~15 °C | ||||||||||
| Motor Details | Power (kW/HP) | 7.5/10 | 11/15 | 15/20 | 18.5/25 | 22/30 | 30/40 | 37/50 | 45/60 | 55/75 | 75/100 |
| Start Method | VSD Starter | ||||||||||
| Voltage (V/Hz) | 380V 3PH 50HZ (380V-3PH-60HZ / 460V-3PH-60HZ / 220V-3PH-60HZ / 400V-3PH-50HZ / 6000V-3PH-50HZ or other voltages customized) | ||||||||||
| Drive Method | Coupling transmission | ||||||||||
| Oil Content (PPM) | ≤ 3 | ||||||||||
| Connector (Inch) | 3/4" | 3/4" | 1" | 1" | 1" | 1 1/4" | 1 1/4" | 1 1/2" | 1 1/2" | 2" | |
| Noise (dB ±2) | 66 | 68 | 68 | 68 | 68 | 68 | 72 | 72 | 75 | 78 | |
| Dimension | Length (mm) | 900 | 1100 | 1100 | 1060 | 1060 | 1060 | 1500 | 1500 | 1800 | 1900 |
| Width (mm) | 700 | 750 | 750 | 820 | 820 | 820 | 1000 | 1000 | 1230 | 1230 | |
| Height (mm) | 930 | 1000 | 1000 | 1220 | 1220 | 1220 | 1290 | 1290 | 1570 | 1570 | |
| Weight (kg) | 140 | 200 | 210 | 235 | 296 | 336 | 443 | 466 | 834 | 917 | |
We are a factory, and currently, we operate 2 factories.
We offer a 13-month warranty starting from the delivery date.
Yes, of course, we provide standard spare parts.
For 380V 50HZ specifications, we can deliver the goods within 10 days. For other custom voltages or colors, delivery will be arranged within 30 days.
Yes, with our professional design team, OEM orders are highly welcome.
