Ideal for manufacturing, automotive, textiles, food & beverage, pharmaceuticals, and electronics industries, where stable air supply and energy efficiency are critical.
| Items | XZV-8A | XZV-11A | XZV-15A | XZV-18A | XZV-22A | XZV-30A | XZV-37A | XZV-45A | XZV-55A | XZV-75A |
|---|---|---|---|---|---|---|---|---|---|---|
| Air Flow 0.7MPa (m³/min) | 1.1 | 1.8 | 2.5 | 3.0 | 3.7 | 5.0 | 6.5 | 7.4 | 10.0 | 13.4 |
| Air Flow 0.8MPa (m³/min) | 1.0 | 1.7 | 2.3 | 2.9 | 3.5 | 4.8 | 6.2 | 7.0 | 9.6 | 12.6 |
| Air Flow 1.0MPa (m³/min) | 0.9 | 1.5 | 2.0 | 2.7 | 3.1 | 4.3 | 5.6 | 6.2 | 8.5 | 11.2 |
| Air Flow 1.3MPa (m³/min) | 0.7 | 1.2 | 1.7 | 2.2 | 2.6 | 3.6 | 4.5 | 5.5 | 7.2 | 9.8 |
| Exhaust Temperature | ≤ Ambient Temp +8~15℃ | |||||||||
| Power (kW/HP) | 7.5/10 | 11/15 | 15/20 | 18.5/25 | 22/30 | 30/40 | 37/50 | 45/60 | 55/75 | 75/100 |
| Starting Mode | VSD Starter | |||||||||
| Power Supply | 380V 3PH 50Hz | |||||||||
| Transmission | Coupling | |||||||||
| Oil Content | ≤ 3ppm | |||||||||
| Air Outlet Size | 3/4″ | 3/4″ | 1″ | 1″ | 1″ | 1 1/4″ | 1 1/4″ | 1 1/2″ | 1 1/2″ | 2″ |
| Noise dB(A) | 66 | 68 | 68 | 68 | 68 | 68 | 72 | 72 | 75 | 78 |
| Dimension (L×W×H mm) | 900×700×930 | 1100×750×1000 | 1100×750×1000 | 1060×820×1220 | 1060×820×1220 | 1060×820×1220 | 1500×1000×1290 | 1500×1000×1290 | 1800×1230×1570 | 1900×1230×1570 |
| Weight (kg) | 140 | 200 | 210 | 235 | 296 | 336 | 443 | 466 | 834 | 917 |
